Integra DTR 30.7

1 000,00€

Integra DTR 30.7

Supporting the latest Dolby Atmos and DTS:X formats, 4K/ 60 Hz video and an array of network options, the DTR-30.7 combines next-gen features with stunning Integra sound.

COLAB Integra DTR 30.7

DTS:X Compatible
Get ready for the next generation of object-based, multi-dimensional sound from DTS. No longer limited by specific channels- DTS:X allows audio content to move with fluidity, accuracy and immersiveness as never before. Auditory details move in front of, behind, beside and even above the audience. DTS:X also allows you to fine tune and customize the audio experience with adjustments available for speaker layout, dialog control and dynamic range - to help personalize the sonic experience to your liking.

Feel Every Dimension in Dolby AtmosTM
Dolby Atmos transports you from an ordinary moment into an extraordinary experience with draw-dropping realism that fills your room with amazing richness and depth. Mixing a traditional channel-based audio bed with object-oriented sounds- music, movies, and video games come alive in breathtaking detail and flow in precise choreography all around you, making you feel like you are truly there. The Dolby Surround upmixer expands audio content that is not mixed in Dolby Atmos for playback on any speaker configuration, including overhead speakers- giving you a better audio experience even without a Dolby Atmos soundtrack.

Ready for the Ultra HD Revolution
Full Bandwidth (up to 18Gbps) 4K@50/60 (2160p), 4:4:4 color space and HDCP 2.2 support ensure that this Integra receiver is ready for the UltraHD Revolution. Crystal clear video playback that offers 4 times resolution of 1080p as well as support of the newest High Dynamic Range (HDR) format to provide vastly enhanced realism by enabling greater detail for both the dark and bright parts of an image. Gradations, shadows and other details come alive as never before.

Wireless Network Streaming Services
The DTR-30.7 is ready to serve up your favorite tunes with ease. Whether you are using your smartphone or tablet via Bluetooth, AirPlay or SpotifyConnect or using the plethora of built-in streaming services such as Pandora, Sirius/XM Internet Radio, Slacker and TuneIn or hi-res audio from your home network- the DTR-30.7 has you covered. The free Integra Remote app puts these options at your fingertips and allows for easy control and playback from any zone. Sit back, relax, que up your favorite station, artist, or playlist- and enjoy!

COLAB Integra DTR 30.7

Industry-Leading Digital-to-Analog Conversion (DAC)
The Asahi Kasei AK4458 384 kHz/32-bit high-performance digital-to-analog converter achieves the industry's best low distortion characteristics using a unique digital filtering process focused on the "original sound" - authoritative, rich, and pure. This ultra-precise DAC unlocks the full potential of virtually any compressed, lossless, or - especially critical today- Hi-res Audio format; maximizing the sonic performance of your favorite music, movies and more. Supported formats include AAC, Apple Lossless, Dolby TrueHD, DSD 5.6 MHz, FLAC, LPCM, MP3, OggVorbis, WAV, WMA, and WMA Lossless.

Hand Selected Audio Tuned Parts
Sound quality is the key factor in Integra's design process. Both the preamp and amplification stages of our components utilize hand-selected parts including but not limited to our high current, low impedance power supplies; over-sized storage capacitors, transistors and resistors. These parts are selected for their audiophile quality and acoustically transparent characteristics. This provides lower noise and more accurate frequency response; outstanding signal tracking and linearity; unsurpassed dynamic range; precise channel separation; sonic and visual playback accurate to the artist's intended vision; and enduring quality, even under the most challenging circumstances.

Hi-Resolution Audio Powerhouse
Hear your music library as never before. High-Resolution means studio quality sound recording to extract additional elements, nuances and details far beyond the capabilities of standard CD to virtually put you in the room with your favorite musician. Integra makes it incredibly easy to access and enjoy audio files mastered in high-resolution (up to 192kHz/24-bit) stored on a computer, media server, network-attached storage (NAS) or USB thumb drive with zero loss in audio quality. Virtually every hi-resolution and lossless format is supported- 2.8 or 5.6 MHz DSD, Dolby® TrueHD as well as gapless playback of FLAC, WAV, ALAC and WMA files. Dual 32-bit DSP Engines and premium quality Texas Instruments digital to analog converters ensure effortless high-quality playback and excellent sound quality.

Zone 2 Digital Audio
The DTR-30.7 features an overabundance of Zone 2 capabilities. Using high-quality digital-to-analog conversion- internal digital sources such as Pandora, Sirius/XM, Slacker and Spotify as well as external sources connected via Coax and Toslink (2-ch PCM only) are available in a Zone 2- making it easy to share your favorite tunes throughout the house. Use the free Integra Remote app to fully control the Zone 2 functions from your fingertips- whether you need to use the internal amplifier or want to use the RCA outputs to a secondary amp like the ADM-20.4 for even more power- the DTR-30.7 has you covered with plenty of flexibility and ease-of-use.

Integra's Original Approach to Room Correction
AccuEQ calibration technology reveals the true potential of your speakers by eliminating standing waves from your listening space. These acoustic peaks distort the audio image and prevent your loudspeakers from voicing the sound as their designers intended. AccuEQ lets you experience the whole sonic picture without changing your speaker system's unique personality.

Perfect for Custom Installation
You can't say integration without Integra. Integra products are designed and engineered to meet the demands of custom audio/video systems installers. The DTR-30.7 includes system integration connectivity such as RS232 and IP control with support for 2-way communication with 3rd party home automation systems. A pair of infrared (IR) inputs and an IR output make for a clean, reliable installation and allow pass-through of IR signals to control other devices connected to the DTR-30.7, such as a TV or Blu-ray player. Three fully programmable 12 volt triggers can be used to raise/lower a projection screen, power on/off an external amplifier and open/close the drapes all with the touch of a button! Optional rack mount kits for all models provide a clean, finished look when installed in racks and cabinets. Integra works closely with control systems partners such as Savant, Crestron, URC, and RTI, and supports Control4 Simple Device Discovery Protocol (SDDP) and AMX Device Discovery for simplified system integration.

COLAB Integra DTR 30.7

SPECIFICATIONS

AMPLIFIER:
# Channels 7.2
POWER (8 Ω 20-20kHZ 0.08%) / CH 100
Amplifier Frequency Response (WRAT) 5Hz - 100kHz
High Current Power Supply Massive High Power Transformer
THX Certified
Continuous 6 Ω Rated ✓
Low Impedance Drive- Certified 4 Ω
Hand Selected Parts to Ensure Low Impedance Performance Custom- Audio Tuned
Discrete Output Stages for All Channels ✓
All Channels Equal Power Output ✓
PUSH-PULL Amplifier Design ✓
3-Stage Inverted Darlington Circuitry to Remove Distortion
Independent Block Construction (Amp / Preprocessor)
Independent Power Supply 2
Bi-amp Capability - Front L/R Channels ✓

PROCESSING:
Dolby Atmos and Dolby Surround ✓
Dolby TrueHD ✓
DTS:X and DTS Neural:X ✓ (Future Firmware Update)
DTS-HD Master Audio ✓
THX Processing Modes & Loudness Plus
AccuEQ Automatic Room Calibration Advanced
Phase-Matching Bass Boost ✓
GAME Surround Modes (Rock, Action, Sports, Role Play) ✓
Advanced Music Optimizer to Enhance Compressed Audio Files ✓
Premium Quality Digital-to-Analog Conversion 384k / 32-bit AKM 4458
32-Bit DSP Chip for Advanced Processing ✓
Ultra-Low-Jitter Circuitry to Improve Audio ✓
Adjustable Crossover by Channel Pair 40/45/50/55/60/70/80/90
100/110/120/130/150/200 Hz
Accurate Speaker Distance Setting 0.1 - foot
A/V Sync Delay (by Source) -100 to +500 ms

CONNECTIVITY:
HDMI Inputs / Output(s) 7 / 2
HDMI 4K / 60 Hz- Capable HDMI Terminals with HDR Support
HDCP 2.2 Copy-Protection Compatibility 3 in / 2 out
HDMI Support for High Dynamic Range (HDR) ✓
4K / 60 Hz 4:4:4 Colorspace Support ✓
HDMI Support for 3D, Audio Return Channel and CEC ✓
HDMI Support for Deep Color, x.v.Color, LipSync ✓
HDMI Support for DVD-Audio, SACD, Multichannel PCM ✓
Front Panel HDMI Input ✓
HDBaseT Output
Analog to HDMI Upconversion From 480i/576i
4K Passthrough ✓
Component Video Inputs / Output(s) 2 / 0
Composite Video Inputs / Output(s) 3 / 0
Digital Audio Inputs (COAX / OPT) 1 / 2
Analog Audio Inputs / Output(s) 7 / 0
Phono Input ✓
Front Panel A/V Input
Analog Pre-outs 7.2

NETWORK / USB:
Supports Integra Remote Apps for iPod / iPhone and Android-Powered Devices ✓
Apple Airplay ✓
iPod / iPhone / iPad Ready ✓
DLNA v1.5 Certified ✓
"Home Media" Sharing ✓
Pandora ✓
SiriusXM Internet Radio ✓
Slacker ✓
Spotify ✓
Spotify Connect ✓
TuneIn Radio ✓
DSD Support (2.8 MHz) ✓
Double DSD Support (5.6 MHz) ✓
Dolby TrueHD Support ✓
Apple Losless (ALAC) Support ✓
WAV Support ✓
WMA Lossless Support ✓
AAC Support ✓
Ogg Vorbis Support ✓
FLAC Support ✓
LPCM Support ✓
MP3 Support ✓
USB Input for Streaming Audio ✓
Wireless Network Wi-Fi Certified
Bluetooth Built-in
Firmware Updates via Network and USB ✓
Firmware Update Notification ✓

MULTIZONE:
Powered Zone 2 ✓
Powered Zone 3
Fixed or Variable Zone 2 Line Out ✓
Fixed or Variable Zone 3 Line Out
Zone 2 Video Output
Zone 2 Audio DAC SPDIF, NET, USB
Zone 3 Audio DAC

INTEGRATION ACCESS:
Bi-directional RS-232 Control Port ✓
Bi-directional Ethernet Control Port ✓
Rear Panel IR Input / Output 2 / 1
RIHD (Remote Interactive over HDMI) ✓
RI System Control ✓
12V Trigger (with Adjustable delay) x3, Assignable

MISCELLANEOUS:
Pre-programmed Remote ✓
GUI for Remote Control Programming ✓
GUI for Setup Menu ✓
Quick Setup Menu ✓
Input Name Edit Fully Customizable
HDMI Standby "Through" Mode Assignable
Dealer Settings Memory Store & Recall Function ✓
Screensaver Function ✓
Hybrid Standby to Reduce Power Consumption ✓
Smart Grid Ready ✓
Anti-Resonant Aluminum Front Panel ✓
Gold-Plated RCA Terminals ✓
Oversized Detachable AC Cord ✓
Rack Mount Kit Available IRK-155-3C
Warranty 3 YEARS
